12"X24"
300mm x 600mm x 22mm
11 7/8" x 23 5/8" x 0 7/8"
24"X24"
600mm x 600mm x 22mm
23 5/8" x 23 5/8" x 0 7/8"
24"X36"
600mm x 900mm x 22mm
23 5/8" x 35 1/2" x 0 7/8"
STEP 48"X16"
1,200mm x 150mm x 400mm
47 1/4" x 5 7/8" x 15 3/4"
STEP 72"X16"
1,800mm x 150mm x 400mm
70 7/8" x 5 7/8" x 15 3/4"
COPING W/ DL ROCK FACE
355mm x 1,200mm x 50mm
14" x 47 1/4" x 2"
COPING W/ DL ROCK FACE
355mm x 50mm x 1,800mm
14" x 2" x 70 7/8"
12"X24"
300mm x 600mm x 22mm
11 7/8" x 23 5/8" x 0 7/8"
24"X24"
600mm x 600mm x 22mm
23 5/8" x 23 5/8" x 0 7/8"
24"X36"
600mm x 900mm x 22mm
23 5/8" x 35 1/2" x 0 7/8"
STEP 48"X16"
1,200mm x 150mm x 400mm
47 1/4" x 5 7/8" x 15 3/4"
STEP 72"X16"
1,800mm x 150mm x 400mm
70 7/8" x 5 7/8" x 15 3/4"
COPING W/ DL ROCK FACE
355mm x 50mm x 1,800mm
14" x 2" x 70 7/8"
| Units per Sq Ft | Units per Crate | Lbs per Unit | Sq Ft per Unit | SQFT per Crate | Lbs per Crate | Lin Ft per Unit - Soldier | Soldier Lnft per Crate |
|---|---|---|---|---|---|---|
| 12"X24" | COPING W / DL ROCK FACE | STEP 48"X16" | 24"X36" | STEP 72"X16" | 24"X24" | |
| Units per Sq Ft | 0.5 | 0.14286 | 0.1875 | 0.16667 | 0.125 | 0.25 |
| Units per Crate | 90 | 12 | 6 | 30 | 4 | 40 |
| Lbs per Unit | 23.88 | 180.77667 | 429.89667 | 71.64 | 644.845 | 47.76 |
| Sq Ft per Unit | 2 | 7 | 5.33333 | 6 | 8 | 4 |
| SQFT per Crate | 180 | 84 | 32 | 180 | 32 | 160 |
| Lbs per Crate | 2149.2 | 2169.32 | 2579.38 | 2149.2 | 2579.38 | 1910.4 |
| Lin Ft per Unit - Soldier | - | - | - | - | 6 | - |
| Soldier Lnft per Crate | - | - | - | - | 24 | - |
Limestone Slabs
Limestone is a thinly quarried slab with sharp zero-bevel edges. Limestone can be used residentially or commercially, but is not suitable for any vehicular applications. Porcelain can also be used in commercial roof deck pedestal applications where a thinner/lighter module is specified. Consult the project engineer for specific installation instructions for roof deck applications.
OVER CONCRETE INSTALLATION – Limestone slabs must be installed on a stable base. The best way to achieve this is to mortar the units on to a poured concrete pad - preferably a new concrete pad, although existing concrete can be used. It is recommended that you have a minimum 4” of ¾” crusher run gravel under the pad for support and drainage, (use any road base gravel in accordance with ASTM-D2940) compacted to 98% Standard Proctor Density (SPD).
Special Notes: Concrete Direct Overlay –
HANDLING – Exercise caution when handling this product, as contact between its zero-bevel edges may cause damage.
EDGE RESTRAINT – not required when installed over concrete. Use manufacturer’s edge restraint system for high density foam installation.
CLEANERS – Limestone slabs clean with simple soap and water. If the stains are more persistent, only use Uni-Care Stone cleaning products. Unicare Products
Unilock has partnered with United Stonecare, a UK company with over 30 years experience in the field of specialized cleaner and sealer products for natural stone.
Visit the website by clicking on the button below or contact us for information and guidance on how to ensure your external stone are easy to maintain and retain their beautiful appearance. https://www.unicare-products.com/
caution – Limestone can be slippery when wet.
Download Technical Sheet
